Simex Planers for Excavators
Ideal for effective milling of asphalt or cement on regardless of the surface. The Simex excavator planers also allow the possibility to reuse milled material for backfilling trenchers.
 |
 |
SPECIFICATIONS
| Model | Performer | Standard drum | Special drums | Operating weight (kg) |
Required oil flow (l/min) |
Required oil pressure | Excavator weight | |||||
| Width | Depth | Width | Max Depth | Min Distance from side path |
Rotation angle of the swing support |
|||||||
| PLB200 | Optional | 200 | 0 – 70 | 50 – 250 | 125 | 40 (20*) | 120 degrees | 185 | 30 – 50 | 250 – 180 | 2 – 4 |  |
| PLB300 | Optional | 300 | 0 – 100 | 50 – 300 | 130 | 50 (25*) | 127 degrees | 390 | 45 – 75 | 250 – 180 | 3 – 6 | |
| PLB350 | Optional | 350 | 0 – 120 | 50 – 350 | 150 | 50 (27*) | 118 degrees | 530 | 75 – 140 | 250 – 180 |
5 – 9 |
|
| PLB450 | Standard | 450 | 0 – 150 | 75 – 450 | 150 | 50 (25*) | 127 degrees | 710 | 75 – 140 | 250 – 180 | 7 – 13 | |
| PHD450 | Standard | 450 | 0 – 180 | 75 – 450 | 220 | 75 (40*) | 102 degrees | 900 | 90 – 140 | 250 – 180 | 10 – 16 | |
| PLB600 | Standard | 600 | 0 – 150 | 75 – 600 | 170 | 65 (30*) | 112 degrees | 985 | 100 – 200 | 300 – 180 | 14 – 18 | |
| PHD600 | Standard | 600 | 0 – 200 | 75 – 600 | 250 | 75 (40*) | 105 degrees | 1200 | 120 – 200 | 300 – 180 | 16 – 24 | |
